Item ID # RSAR
Radius Slide In Wall Inset Lightboxes
Item ID # RSAR
Radius Slide In Wall Inset Lightboxes

Product Highlights

  • Wall Inset Radius Slide-in Light Boxes
  • Quick and easy changes
  • tool free graphic changes by removing one side of the frame
  • Ideal for recessed wall applications
  • Stylish radius face frame is perfect for high traffic areas
  • UL Rated & UL Listed
  • Electrical: 120v / 60hz
  • Overall Depth: 5 1/8" DEEP
  • Frame Width:1"
  • Lighting Specs: T8 & T12 Fluorescent Bulbs
  • ADA Compliant (once recessed)
  • 23 Standard sizes
  • 3 Finishes: Anodized Silver | Powdercoat Black | Brass
  • 1/8" White Difusser Included
  • Protective Sheet: Clear 1/16" Overlay
  • Exit Back Near Bottom Center (subject to change according to box style)
  • Larger sizes will ship via FREE FREIGHT (see Size Chart for details)
  • Hardwire Connection: Electrical lead out the back of box
  • Call for Custom Backlit Light Boxes Indoor and Outdoor

NOTE TO INSTALLER
Wall cut out (wall opening) needs to be 5/8" larger than the light box insert (graphic) size

See More

Multiple Options

Lightbox Frame Finishes
Many More...

Quantity Discounts

QTY Discount (%)
QTY 1-4 0%
QTY 5-9 10%
QTY 10-24 15%
QTY 25-49 20%
QTY 50-99 0%
Get help buying. Chat now or
Call 800-289-1539
Overview
Specifications
Size Chart
Product Options
Warranty & Returns
Shipping
Product Details
  • Wall Inset Radius Slide-in Light Boxes
  • Quick and easy changes
  • tool free graphic changes by removing one side of the frame
  • Ideal for recessed wall applications
  • Stylish radius face frame is perfect for high traffic areas
  • UL Rated & UL Listed
  • Electrical: 120v / 60hz
  • Overall Depth: 5 1/8" DEEP
  • Frame Width:1"
  • Lighting Specs: T8 & T12 Fluorescent Bulbs
  • ADA Compliant (once recessed)
  • 23 Standard sizes
  • 3 Finishes: Anodized Silver | Powdercoat Black | Brass
  • 1/8" White Difusser Included
  • Protective Sheet: Clear 1/16" Overlay
  • Exit Back Near Bottom Center (subject to change according to box style)
  • Larger sizes will ship via FREE FREIGHT (see Size Chart for details)
  • Hardwire Connection: Electrical lead out the back of box
  • Call for Custom Backlit Light Boxes Indoor and Outdoor

NOTE TO INSTALLER
Wall cut out (wall opening) needs to be 5/8" larger than the light box insert (graphic) size

Ordering Options

Lightbox Orientation: Portrait or Landscape

Description

Create a sophisticated presentation for your message with our Wall Inset Radius Slide lightbox. This model offers easy slide access with a narrow 1" face frame. Perfect for ceiling applications, simply remove one frame rail and slide in your poster. Wall Inset light boxes lend an aura of subtle sophistication to your graphics.

These elegant displays feature a unique construction that enables the light box portion to mount into the wall. Only the radius frame and your graphic are visible. These light boxes are hard-wired for easy installation.

Hardwire Connection Knockout out Back of Lightbox
Wall Inset lightbox installations require direct connections to the power supply. An electrical lead is positioned out the back of the lightbox for a licensed electrician to install.

Downloads

Product Sheet

Specifications

General Info


Application Type: Indoor

Display Type: Poster Light Box

Finishes: Black, Gold, Silver

Header: No

Lighting: Fluorescent (Included)

Number of Sides: One Sided

Orientation: Landscape, Portrait, Square

Placement Type: Wall Mount

Dimensions


Overall Depth: 5 1/8"

Sizes: 11" x 14", 16" x 20", 22" x 28", 24" x 24", 24" x 36", 24" x 48", 24" x 60", 30" x 30", 36" x 36", 36" x 48", 36" x 60", 36" x 72", 40" x 60", 48" x 48", 48" x 60", 48" x 72", 48" x 96"

Frame Info


Corner Style: Mitered Corners

Frame Shape: Flat Face

Frame Style: Slot Opening

Frame Type: Aluminum

Frame Width: 5 1/8"

Matboard Info


Decorative Mat Border Included: No

Size Chart

RSAR-1114
Interior Dimensions: 11" x 14"
Overall Size: 12 3/8" x 15 3/8"
Viewable Area: 10 1/4" x 13 1/4"
Ships Via: UPS
Shipping Weight: 12
RSAR-1620
Interior Dimensions: 16" x 20"
Overall Size: 17 3/8" x 21 3/8"
Viewable Area: 15 1/4" x 19 1/4"
Ships Via: UPS
Shipping Weight: 17
RSAR-2024
Interior Dimensions: 20" x 24"
Overall Size: 21 3/8" x 25 3/8"
Viewable Area: 19 1/4" x 23 1/4"
Ships Via: UPS
Shipping Weight: 25
RSAR-2030
Interior Dimensions: 20" x 30"
Overall Size: 21 3/8" x 31 3/8"
Viewable Area: 19 1/4" x 29 1/4"
Ships Via: UPS
Shipping Weight: 29
RSAR-2228
Interior Dimensions: 22" x 28"
Overall Size: 23 3/8" x 29 3/8"
Viewable Area: 21 1/4" x 27 1/4"
Ships Via: UPS
Shipping Weight: 31
RSAR-2424
Interior Dimensions: 24" x 24"
Overall Size: 25 3/8" x 25 3/8"
Viewable Area: 23 1/4" x 23 1/4"
Ships Via: UPS
Shipping Weight: 29
RSAR-2430
Interior Dimensions: 24" x 30"
Overall Size: 25 3/8" x 31 3/8"
Viewable Area: 23 1/4" x 29 1/4"
Ships Via: UPS
Shipping Weight: 32
RSAR-2436
Interior Dimensions: 24" x 36"
Overall Size: 25 3/8" x 37 3/8"
Viewable Area: 23 1/4" x 35 1/4"
Ships Via: UPS
Shipping Weight: 37
RSAR-2448
Interior Dimensions: 24" x 48"
Overall Size: 25 3/8" x 49 3/8"
Viewable Area: 23 1/4" x 47 1/4"
Ships Via: UPS
Shipping Weight: 47
RSAR-2460
Interior Dimensions: 24" x 60"
Overall Size: 25 3/8" x 61 3/8"
Viewable Area: 23 1/4" x 59 1/4"
Ships Via: UPS
Shipping Weight: 55
RSAR-3030
Interior Dimensions: 30" x 30"
Overall Size: 31 3/8" x 31 3/8"
Viewable Area: 29 1/4" x 29 1/4"
Ships Via: UPS
Shipping Weight: 37
RSAR-3040
Interior Dimensions: 30" x 40"
Overall Size: 31 3/8" x 41 3/8"
Viewable Area: 29 1/4" x 39 1/4"
Ships Via: UPS
Shipping Weight: 48
RSAR-3636
Interior Dimensions: 36" x 36"
Overall Size: 37 3/8" x 37 3/8"
Viewable Area: 35 1/4" x 35 1/4"
Ships Via: UPS
Shipping Weight: 54
RSAR-3649
Interior Dimensions: 36" x 49"
Overall Size: 37 3/8" x 49 3/8"
Viewable Area: 35 1/4" x 37 1/4"
Ships Via: UPS
Shipping Weight: 59
RSAR-3660
Interior Dimensions: 36" x 60"
Overall Size: 37 3/8" x 61 3/8"
Viewable Area: 35 1/4" x 59 1/4"
Ships Via: Freight
Shipping Weight: 80
RSAR-3672
Interior Dimensions: 36" x 72"
Overall Size: 37 3/8" x 73 3/8"
Viewable Area: 35 1/4" x 71 1/4"
Ships Via: Freight
Shipping Weight: 94
RSAR-4060
Interior Dimensions: 40" x 60"
Overall Size: 41 3/8" x 61 3/8"
Viewable Area: 39 1/4" x 59 1/4"
Ships Via: Freight
Shipping Weight: 88
RSAR-4362
Interior Dimensions: 43" x 62"
Overall Size: 44 3/8" x 63 3/8"
Viewable Area: 42 1/4" x 61 1/4"
Ships Via: Freight
Shipping Weight: 98
RSAR-4848
Interior Dimensions: 48" x 48"
Overall Size: 49 3/8" x 49 3/8"
Viewable Area: 47 1/4" x 47 1/4"
Ships Via: Freight
Shipping Weight: 76
RSAR-4860
Interior Dimensions: 48" x 60"
Overall Size: 49 3/8" x 61 3/8"
Viewable Area: 47 1/4" x 59 1/4"
Ships Via: Freight
Shipping Weight: 91
RSAR-4972
Interior Dimensions: 49" x 72"
Overall Size: 49 3/8" x 73 3/8"
Viewable Area: 47 1/4" x 71 1/4"
Ships Via: Freight
Shipping Weight: 110
RSAR-4884
Interior Dimensions: 48" x 84"
Overall Size: 49 3/8" x 85 3/8"
Viewable Area: 47 1/4" x 83 1/4"
Ships Via: Freight
Shipping Weight: 131
RSAR-4896
Interior Dimensions: 48" x 96"
Overall Size: 49 3/8" x 97 3/8"
Viewable Area: 47 1/4" x 95 1/4"
Ships Via: Freight
Shipping Weight: 158

Product Options

Lightbox Frame Finishes
Anodized Silver
Powdercoat Black
Brass

Warranty & Returns

180 Day Limited Life Warranty (Magnuson-Moss Act Applies)

This product is warranted against all defects in material or workmanship for 180 DAYS. This warranty does not cover replacement due to customer misuse or abuse.

Products to be found defective in material or workmanship within this period of time will be repaired or replaced at the discretion of the manufacturer. The defective product, however, must be returned by the customer prepaid for examination and inspection. Once repaired or replaced, outbound shipping costs will be incurred and charged to the customer.

Please call our customer service for a RMA # (return authorization number). No returns for warranty related issues will be accepted without such authorization.

Return & Exchange Policy

Customer satisfaction is our top priority. We want you to be completely satisfied with your purchase. This product is custom built for each order and cannot be returned for any reason. All custom orders are non-returnable unless defective in material or workmanship.

Please call our customer service for a RMA # (return authorization number). No returns will be accepted without such authorization.

Shipping

QTY: QTY 1-4
Discount (%): 0%
Ship from factory: Usually Ships in 5-10 Business Days
QTY: QTY 5-9
Discount (%): 10%
Ship from factory: Usually Ships in 10-15 Business Days
QTY: QTY 10-24
Discount (%): 15%
Ship from factory: Usually Ships in 3-4 Weeks
QTY: QTY 25-49
Discount (%): 20%
Ship from factory: Usually Ships in 4-5 Weeks
QTY: QTY 50-99
Discount (%): 0%
Ship from factory: Request a Quote

Quantity: 1 (you can change QTY in the right column)

Lead time to ship: September 26, 2018 - September 26, 2018

Delivery estimate: September 27, 2018 - October 02, 2018

* Delivery Estimate refers to the Shipping Time or transit time of your order once the items have been shipped. The delivery estimates above refer to standard ground delivery. Depending on the actual ship date, shipping service selected, and the ship to zip code, your order may arrive sonner than the estimated ship date shown above. Business days: Monday - Friday (excluding major holidays)
